Chroma Model 19052 19053 19052 Tester HIPOT - indisponibil

  • Descriere produs
  • Fisa tehnica
  • Fisiere disponibile
  • Accesorii compatibile

CARACTERISTICI CHEIE

  • Tester 3 în 1: AC, DC, IR
  • Tensiune de ieșire programabilă la 5 kV AC și 6 kV DC
  • Curent de declanșare programabil la 30 mA AC și 10 mA DC
  • Rezistență de izolație la 50GΩ/1000V DC
  • SCANNER încorporat cu 8 canale (numai 19053)
  • SCANNER cu 4 canale încorporat (numai 19054)
  • Verificare deschis/scurtcircuit (OSC)
  • Întreruperea defectului la pământ (GFI)
  • Detectare ARC (Flashover)
  • Stocare a 50 de setări de teste cu 100 de pași per configurare
  • Dispozitiv opțional de testare a transformatorului (numai 19053)
  • Interfață RS-232 standard

Interfață GPIB opțională



Seria Chroma Hipot Tester 19050 oferă 3 modele la alegere. 19052 pentru testarea AC/DC/IR Hipot și măsurători ale rezistenței de izolație (IR), 19053 care combină atât testele AC și DC Hipot și măsurători IR cu capacitate de canal de scanare 8HV într-o singură unitate compactă și 19054 care combină atât AC și DC Teste DC Hipot și măsurători IR cu capacitatea canalului de scanare 4HV într-o singură unitate compactă. Panourile frontale ale febrelor le fac ușor de operat.

Model

19071

19073

19052

19053

19054

Mode

ACWV

ACWV / DCWV / IR

ACWV / DCWV / IR

ACV / DCV / IR / SCAN



Scanner Unit

-

-

-

8 ports,± phase

4 ports,± phase

Withstanding Voltage Test



Output Voltage

AC : 0.05 ~ 5kV, DC : 0.05 ~ 6kV



Load Regulation

≦ (1%+5V)



Voltage Resolotion

2V



Voltage Accuracy

±(1% of reading + 5 counts)



Cutoff Current

AC : 0.1~20mA

AC : 0.1mA ~ 20mA
DC : 0.01mA ~ 5mA

AC : 0.1 ~ 30mA,
DC : 0.01 ~ 10mA



Current Resolution

AC : 1µA, DC : 0.1µA



Current Accuracy

±(1% of reading + 5 counts)



Output Frequency

50Hz / 60Hz



Test Time

0.3 ~ 999 sec., continue



Ramp Time

0.1 ~ 999 sec., off



Fall Time

0.1 ~ 999 sec., off



Dwell Time

0.1 ~ 999 sec., off



Waveform

Sine wave



Insulation Resistance



Output Voltage

-

DC : 0.05 ~ 1kV



Voltage Resolution

-

2V



Voltage Accuracy

-

±(1% of reading + 5 counts)



IR Range

-

1MΩ ~50GΩ

1MΩ ~10GΩ



Resistance
Accuracy

≧500V

1.00MΩ ~ 25.00MΩ

-

±(4% of reading + 5 counts)

± (5% of reading + 2% of full scale)

22.0 MΩ ~250.0MΩ

-



0.220GΩ ~1.000GΩ

-

±(5% of reading + 2% of full scale)



1.000GΩ ~2.500 GΩ

-

±(7% of reading + 5 counts)

±(5%ofreading+2%offullscale)



2.20GΩ ~10.00GΩ

-

±(15%ofreading+1%offullscale)



10.00GΩ ~50.00GΩ

-

±(12% of reading + 5 counts)

±(15% of reading + 1% of full scale)



≦ 500V

0.10 MΩ ~25.00MΩ

-

±(7% of reading + 5 counts)

± (10% of reading + 2% of full scale)



22.0MΩ ~250.0MΩ

-



0.220 GΩ ~1.000GΩ

-

±(15% of reading + 1% of full scale)



Flashover (ARC) Detection



Setting Mode

Programmable setting



Detection Current

AC : 1mA ~ 20mA

AC : 1mA ~ 20mA
DC : 1mA ~ 5mA

AC : 1mA ~ 15mA ; DC : 1mA ~ 10mA



Secure Protection Function



Fast Output Cut-off

0.4ms after NG happen



Ground Fault Interrupt

0.5mA ± 0.25mA AC, ON/OFF



Panel Operation Lock

Present password



Continuity Check

1~5Ω ± 0.2Ω , ON/OFF

1Ω ± 0.2Ω , ON/OFF



GO/NG Judgment Window



Indication, Alarm

GO : Short sound, Green LED ; NG : Long sound, Red LED



Data Hold

Least tests data memories



Memory Storage

10 tests setups with 60 steps pre setup

99 steps or 99 groups for total 500 memory



Remote & Interface



Remote control

Input : Start, Stop, Interlock (at 11 pin terminal block only)
Output : Under test, Pass, Fail



Communication Interface

RS485 (option)

RS232 (standard), GPIB (option)



General



Operation Environment

Temperature : 0℃~40℃ ; Humidity : 15% to 95% R.H @ ≦ 40℃



Power Requirements

100V/120V/220V/240V (AC ± 10%), 50/60Hz



Power Consumption

300W

500W



Dimension (W x H x D)

270x105x350 mm/10.63x4.13x13.78 inch

320 x 105 x 400 mm/12.6x4.13x15.75 inch



Weight

11 kg / 24.23 lbs

Approx. 15.4 kg / 33.92 lbs



Certification

UL, TUV, CE

UL, TUV, CE

CE

UL, TUV, CE
